The TM-U220 is a robust, high performance impact receipt printer which is exceptionally easy to use. Featuring drop-in paper load, selectable auto-cutter and clamshell covers for easy access and maintenance, the TM-U220 is very reliable and prints on plain paper in three widths. Epson TM-U220 POS Receipt Printer. Epson TM-U220 Print, scan, and fax. Epson TM-U220 Driver This that can help your work faster and more efficiently.But to run this device, you must install the Epson Epson TM-U220 Driver on this website. Installing and Setting the Connect-It Ethernet Adapter (Type IV) Install the Connect-It Ethernet adapter into the Epson TM series printer. The Type IV adapter can replace the existing adapter and is held in place by 2 screws. If changing a printer to Ethernet you must change the specific dip switch on the Epson printer to allow for the. EPSON TM U220 installation tutorial. Como instalar impresora EPSON TM U220D Modelo M188D - Duration. 2TouchPOS Epson TM-U220B Ethernet Kitchen Printer - Duration.
Features daughter board connectivity option – Gives you access now or in the future to Epson's range of interfaces, including serial, parallel, USB, Ethernet and wireless 802.11b; Wall mounting option – Allows the Epson TM-U220 to be mounted on the wall, ideal for hospitality applications. Increased data buffer at 4KB.
TM-U220 Receipt Printer by Epson The Epson TM-U220 impact printer has been a mainstay in kitchen printing and dry cleaners for many years. The printer uses a ribbon to transfer ink to paper, making it more resistant to smears and discoloration from heat and humidity. Available with a variety of interfaces and cutting methods, the TM-U220 is a solid investment. Return back to support options for Epson TM-U220B Series. Printer drivers, network Wi-Fi drivers, scanner drivers and software. As well as setting up your product to your Windows PC or Mac. If the Epson Product Setup tool is not available for your product continue to the section below.
Additional Images:
Color Options
White, Dark Grey
Lifetime Support 2 Year Warranty20 Day Return PeriodFree Shipping$205.00Models & Options
TM-U220 Receipt Printer
The Epson TM-U220 Receipt Printer series features speedy (4.7 lines per second), high-quality two-color impact printing optimized for high-volume retail and restaurant point of sale operations.
Compared to its predecessor, the TM-U200, the TM-U220 receipt printer is 30% faster, sports a 4k buffer vs the original 1k, and comes with a universal power supply. Other TM-U220 distinguishing qualities include the exclusive Epson Connect-It interface, adjustable paper widths, real drop-in paper loading, 'near-end' and 'paper-out' sensors, and a 2-year warranty.
- Details
- U220A - Series A Has Journal Take Up and Auto-Cutter
- U220B - Series B Has Auto Cutter Only
- U220D - Series D Has No Options
Epson TM-U220
Receipt Paper
Tech Note: The Epson TM-U220 uses TM-U200 printer drivers.
Cables Not Included, See Accessories Below
| Product Specifications | |
|---|---|
| Weight | Type A: Approximately 2.7 kg {5.94 lb} - Type B: Approximately 2.5 kg {5.5 lb} - Type D: Approximately 2.3 kg {5.06 lb} |
| Dimensions | Type A: 160W x 286D x 157.5H - Type B: 160W x 248D x 138.5H - Type D: 160W x 248D x 138.5H |
| Interface | USB Serial Parallel Ethernet |
| Color Options | White, Dark Grey |
| Print Method | Serial impact dot matrix |
| Print Speed | Approximately 4.7 lines per second (printing 40 columns per line at 16 cpi) - Approximately 6.0 lines per second (printing 30 columns per line at 16 cpi, with 1/8' line spacing) (except data transmission and processing time) |
| OPOS Compatible | Yes |
| Character Set | 95 alphanumeric, 48 international characters, Extended graphics: 128 × 12 pages. (15 tables for Japanese model) |
| Character/Line | 35 (font A), 40 (font B, default) (When using 76mm width paper) |
| Operating Temperature | 41°F - 122°C (0°C - 50°C) |
| Print Head Life | 150 million characters (using an average of 2 dots / wire per character) |
| MCBF | 18,000,000 lines |
| Auto Cutter Lifespan | 800,000 Cuts |
| Paper Thickness | 0.06 to 0.085 mm |
| Paper Dimensions | 57.5 - 76 mm (2.26 - 3 in.) |
| Two Color Printing Capabilities | Yes - Black or Black/Red (optional black/red ribbon)) |
| Sensors | Nearly out of paper detector |
| Auto Cutter | Optional - partial or full cut option, can be changed as needed - Method: by separated-blade scissors |
| Wall Mountable | Yes - optional WH-10 wall mounting bracket required |
| Mac Compatible | No |
| In The Box | Printer, users manual, 1 roll of paper, power switch cover, exclusive ribbon cassette ERC-38 (B/R), power supply unit (may not be included with the printer) |
Frequestly Asked Questions
| Downloads |
|---|
| Data Sheet |
| Manual |
| Technical Reference Guide |
| Ethernet Driver & Utility |
| OPOS Driver |
| Serial Emulation Driver |
| Windows Driver |
Epson TM-U220 Reviews
The TM-U220 features a couple of improvements on the already great TM-U200. This is a great Epson impact printer with a fine warranty at a good price. Make sure you buy the correct cables.
Customer Reviews
Find it faster! Click here to compare TM-U220 models by feature.
- Color
- Autocutter
- Other
- autocutter: Yes
- color: Dark Grey
- interface: Ethernet E04
- power supply: Included
- autocutter: Yes
- color: Dark Grey
- interface: USB
- power supply: Included
- autocutter: Yes
- color: Dark Grey
- interface: Ethernet
- other: mPOS
- power supply: Included
- autocutter: No
- color: Dark Grey
- interface: USB
- power supply: Included
- autocutter: No
- color: Dark Grey
- interface: Serial
- power supply: Included
- autocutter: No
- color: Dark Grey
- interface: Parallel
- power supply: Included
- autocutter: Yes
- color: Dark Grey
- interface: Serial
- power supply: Included
- autocutter: Yes
- color: White
- interface: Serial
- power supply: Included
- autocutter: Yes
- color: Dark Grey
- interface: Parallel
- power supply: Included
- autocutter: No
- color: White
- interface: Parallel
- power supply: Included
- color: Dark Grey
- interface: Ethernet
- power supply: Included
- autocutter: Yes
- color: Dark Grey
- interface: Serial
- other: Journal Take Up
- power supply: Included
- autocutter: Yes
- color: White
- interface: Serial
- other: Journal Take Up
- power supply: Included
- autocutter: Yes
- color: White
- interface: USB
- power supply: Included
- autocutter: No
- color: White
- interface: Serial
- power supply: Included
Epson Tm U220d Driver
This model has reached end of life. It has been replaced by C31C514A7881
This model has reached end of life. It has been replaced by C31C514767
This model has reached end of life.
This model has reached end of life.
This model has reached end of life.
This model has reached end of life. It has been replaced by C31C514A7841
This model has reached end of life.
This model has reached end of life.
This model has reached end of life. It has been replaced by C31C514667
